Concept 995112SAUP
POSMarket SKU: Z16458
This model is available in 2 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.
Conversion kit
Product Overview
Flexibility Plus
It can control and monitor two doors with one reader, or one door with two readers. A wide range of Wiegand card formats are supported. Each reader and door can be controlled independently.
Upgradeable to a LAN based Concept 2 Door Access Module
The Standalone 2 Door Access Controller can grow with your needs. By purchasing a firmware upgrade, the Standalone 2 Door Module can be upgraded to become a normal 2 Door Access Module on any Concept 4000 Security/Access system.
Features
- Supports magnetic swipe or Wiegand card readers without the need for an additional interface
- Capacity for 100 cards with full user names
- Provides reed monitoring
- Request to Enter (REN) and Request to Exit (REX) inputs provided
- Inputs for fire or smoke detectors
- Multi-purpose output per door to signal Door Open Too Long (DOTL), Door Forced or Fire Alarm
- Valid/ invalid outputs
- On-board heavy duty lock relays
- Fuse protection of Reader head power
- Real time clock enabling six TimeZones, four of which are user programmable
- Timestamped 64 event hardware Review buffer
- Comes with free management software incorporating full
- Review log functionality
Product Specifications
| Conversion kit. Converts Standalone Two Door Access Module to a Concept 3000 / Access 4000 Cached | |
| Part number | 995112SAUP |
| Physical | |
| Standard Cabinet Dimensions | 305(L) x 140(W) x 72(D) (mm) |
| Equipment Box Dimensions | 325(L) x 250(W) x 112(D) (mm) |
| Installation Environment | 0°C - 40°C @15 - 85% Relative humidity (non-condensing) |
| Electrical | |
| Power Supply Input | 11-14V DC (Typically from separate power supply) |
| Operational Current | 70mA (No relays active and no external load) |
| Max | 210mA |
| Fuse Protection | 500mA |
| Inputs | |
| Zone Inputs | 1 per door (typically used for fire/smoke detector) |
| Door Inputs | Door Reed, REX, REN button per door |
| Reader Ports | 2 |
| Outputs | |
| Relay | 2 (Typically used for door locks) |
| Physical Auxiliaries | 6 (Typically used for Valid/Invalid and alarm indication) |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| 995112SAUP | Converts Standalone 2-Door Access Module to a Cached 2-Door RS485 LAN module | $178.06 | Add to Cart | |
| 993036 | Port 0 Cable & Custom Software for Standalone 2-Door Access Controller | $76.04 | Add to Cart |
Product Accessories
| Filename | Size | ||
|---|---|---|---|
 |
Standalone 2 Door Access Controller Datasheet.pdf | 880KB | Download |
