Newland FR42

$442.75 (incl. GST)

POSMarket SKU: Z20456

NLS369-10200: 2D WIRELESS DESKTOP CPU-BASED DECODING 2D IMAGER DIRECT BT CONNECTION INCL BT USB DONGLE USB TYPE-C

Encased in an IP52-sealed, drop-resistant (up to 1.5m) housing with no movable components, the FR42-BT reinforces its durability both internally and externally, making it well-suited for challenging outdoor settings.

Product Rating
Product Overview
Durable Construction
The FR42-BT, built into an IP52-sealed and drop resistant (1.5m) housing with no moving parts fortifies itself inside and out, is suitable for the tough outdoor environments.

New Generation Product in Simple Appearance
The first wireless desktop products by Newland whose integrated structure design can be placed on the desktop to scan the code without holding it, and it can also be flexibly grasped on both sides.

No Fear of Power off
The battery can be replaced easily and charged respectively.

Outstanding Performance
The FR42-BT is a barcode scanning powerhouse. The megapixel camera allows users to scan 1D and 2D barcodes, including barcodes displayed in a variety of filmed screens, with impressive speed and ease.

Reliable and Stable Wireless Communication
Adopting Bluetooth 5.0 dongle which is strong anti-interference and stable to transmit the data.

Superior Motion Tolerance
Exceptional motion tolerance (1.8m/s) and large FOV (horizontal 62°, vertical 54°) enhance user experience.
Product Specifications
Image Sensor 1080*1280 CMOS
Illumination White LED
Symbologies

2D:

  • PDF417
  • QR Code
  • Data Matrix
  • Micro QR
  • MICRO PDF 417
  • GM CODE
  • Hanxin Code
  • Maxicode
  • Aztec
  • Code ONE

1D:

  • EAN-13
  • EAN-8
  • UPC-A
  • UPC-E
  • ISSN
  • ISBN
  • Codabar
  • Code 128
  • Code93
  • ITF-6
  • ITF-14
  • 1D Interleaved 2 of 5
  • Industrial 2 of 5
  • Standard 2 of 5
  • Matrix 2 of 5
  • GS1 Databar
  • Code 39
  • Code32(Italian Pharma Code)
  • Code 11
  • MSI-Plessey
  • Plessey
Resolution =3mil
Typical Depth of Field EAN-13: 10mm-130mm (13mil)
QR Code: 15mm-110mm (15mil)
Code 39: 35mm-80mm (5mil)
Scan Angle Pitch: ±60°, Roll: 360°, Skew: ±65°
Min. Symbol Contrast 15%
Field of View Horizontal 62°, Vertical 54°
Motion Tolerance 1.8m/s
Physical Dimensions (L×W×H) 82.0×77.0×146.0mm
Weight 209g
Notification Beep, LED
Interfaces Bluetooth 5.0 BLE and HID, Bluetooth Dongle CDC/KBW/HID-POS
Operating Voltage 5VDC±5%
Operating Temperature -10°C to 55°C (14°F to 131°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Humidity 5%~95% (non-condensing)
ESD ±12 KV (air discharge); ±8 KV (contact discharge)
Drop 1.5m/4.9ft
Sealing IP52
Battery Charge Temperature 0°C to 45°C (32°F to 113°F)
Wireless Radio Technology Bluetooth 5.0
Communication Distance Bluetooth 5.0: 50m/164ft (direct line of sight in the open space)
Battery 2000 mAh lithium-ion battery
Expected Charge Time 5 hours
Expected Battery Life 9.5 hours of continuous operation (scan once per 3 seconds)
16 hours of continuous operation (scan once per 10 seconds)
Certifications IEC 62471. RoHS, CE RED (BT only), FCC ID (BT only), IEC 60068-2-31, IEC 60529
```
ModelDescriptionPriceStock
NLS369-10200 2D WIRELESS DESKTOP CPU-BASED DECODING 2D IMAGER DIRECT BT CONNECTION INCL BT USB DONGLE USB TYPE-C $442.75
