Opticon OPI3301
POSMarket SKU: Z2091
This model is available in 2 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.
The OPI3301 is a compact handheld 2D imager using Bluetooth to communicate with other devices. This wireless device is equipped with an aggressive imager providing quick and easy scanning. The lightweight handheld design of the OPI3301 provides an ergonomic fit for all day use, maximizing comfort during operation.
Product Overview
The OPI-3301 is an ultra-lightweight Bluetooth CMOS imager that reads 1D or 2D barcodes for healthcare, retail, point-of-sale (POS), inventory or logistics applications. The OPI-3301 uses LEDs for lighting and features a red laser spot for aiming. Disinfectant-ready plastic makes this scanner ideal for Healthcare applications.
Features- Full spectrum illuminated imager - high performance white LEDs create a wide range of options for scanning - including scanning of red-colored labels.
- Low cost Cordless Handheld 2D Imager
- Laser aiming spot helps user to target within the field of white light
- Up to 10 m Range
- up to 80 Frames/sec
- Easily reads 1D or 2D barcodes for healthcare, retail, POS, inventory or logistics applications
- Long operating time on battery charge
- Ultra-lightweight, yet solid scanner withstands drops up to 1.5 meter onto concrete
- Protection rating: IP42
- Wide environmental specifications: works from -20C/-4 F to 50 C/122 F.
Product Specifications
| Functionality & Operation | |
| Indicators | LED(red/green/blue), buzzer |
| 1D Barcode Symbologies | All standard one-dimension barcodes |
| 2D Code Symbologies | all standard 2D-Codes |
| Wireless communication | Bluetooth® |
| WPAN Features | Bluetooth® Class II compliance v2.1 |
| Optical | |
| Resolution | 5 mil |
| Bar code scanner | 2D Imager |
| Minimal PCS value | 0.45 |
| Electrical | |
| Power Consumption - Standby | 150mA |
| Power Consumption - Operation | 300mA |
| Main battery pack | Li-Ion 1100 mAh, 3,7V |
| Main battery pack operating time | 10hod |
| Battery charging time | 3hod |
| Mechanical | |
| Dimensions | Width: 113mm, Height: 56mm, Length: 137mm |
| Weight | 110g |
| Body housing | ABS plastic |
| Color | black |
| Environment | |
| Operating temperature | -20 to 50°C |
| Storage temperature | -25 to 60°C |
| Shock resistance | drop from 1,5 m onto concrete surface |
| Storage humidity (non-condensing) | 5 to 85% |
| Operating humidity (non-condensing) | 5 to 85% |
| Ingress protection | IP42 |
| Others | |
| Certifications | CE, FCC, Laser Class: CDRH Class II, RoHS, VCCI |
| Warranty | 2 years |
| Resolution | 5 mil |
| Bar code scanner | 2D Imager |
| Minimal PCS value | 0.45 |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| 12920 | OPI-3301 Scanner Only | $495.07 | Add to Cart | |
| OPI3301BKIT-RU | OPI-3301 Scanner and Cradle Kit - Includes Scanner, Charge/Comms Cradle, USB & Serial cable, Power supply. Black | $756.32 | Add to Cart |
| Model | Description | Prices From | |
|---|---|---|---|
| Opticon 6VDC1000 7 (FSR-06) | Plug Pack 6V Reg. | $32.84 | View Product |
| Opticon 12292 | CRD-3301 CommunicationCharging cradle for OPR-3301 with RS232 USb Cable and Power supply Black | $297.00 | View Product |
| Opticon 12901 | Rechargable Battery for the OPR3301 | $85.80 | View Product |
| Filename | Size | ||
|---|---|---|---|
![]() |
OPTICON OPI-3301 Brochure | 246KB | Download |
![]() |
Opticon OPI-3301i Brochure | 1MB | Download |
![]() |
Opticon OPI-3301i Quick Start Guide | 14MB | Download |
![]() |
CRD-3301B Charging Base | 731KB | Download |
![]() |
CRD-3301B Quick Start Guide | 406KB | Download |
![]() |
CHG-3201 Cradle Brochure | 654KB | Download |
![]() |
Opticon OPI3301 Specification Manual | 605KB | Download |
