Axis M1135

$848.38 (incl. GST)

POSMarket SKU: Z14976

01768-001: M1135 Network Camera, HDTV 1080p, H.265, PoE, 3 - 10.5mm VF Lens

Axis' 2 MP premium affordable, compact network camera for surveillance thats easy to install and operate

Product Rating
Product Overview
The Axis M1135/ AXIS-01768-001 is an affordable and compact network camera that delivers superb image quality in 2 MP resolution. The video compression is efficient, as Zipstream technology significantly reduces storage and bandwidth needs. The inbuilt microphone, coupled with it being designed as a visible deterrent, helps to discourage trespassing, antisocial or criminal behaviour. It offers flexible, low-cost installation making it ideal for various industrial or commercial surveillance situations, such as retail stores, indoor markets, and delivery areas.

he M1135 2MP Network Box Camera with 3-10.5mm Lens from Axis Communications uses a 1/3" progressive scan RGB CMOS sensor to capture 1920 x 1080 resolution video at 30 fps. Forensic WDR and Lightfinder technology help the camera produce clear images in challenging and low-light conditions. A CS mount allows you to choose from interchangeable lenses (available separately) to best suit your surveillance application. An included 3-10.5mm varifocal lens delivers a 90 to 33° horizontal field of view.You'll be able to record video with sound thanks to a built-in microphone and an audio input. Integrated PoE technology simplifies connectivity by enabling the transfer of power and data through a single cable. A memory card slot accepts microSD/SDHC/SDXC cardr.

Compliance with ONVIF profiles G, S, and T enables interoperability with a wide range of surveillance devices.

FEATURES
  • 2MP / HDTV at 30fps surveillance
  • Lightfinder and forensic WDR
  • Zipstream with H.264 and H.265
  • Signed firmware and secure boot
  • Day/night functionality
  • Built in microphone for audio recording
Product Specifications
Camera
Sensor 2 MP 1/3" CMOS
Lens Mount CS
Focal Length 3 to 10.5mm
Maximum Aperture f/1.4
Zoom Optical: 3.5x
Lens Field of View Horizontal: 90 to 33°
Vertical: 49 to 19°
IR Cut Filter Mechanical
Day/Night Yes
Minimum Illumination Color: 0.1 Lux
B&W: 0.02 Lux
Shutter Speed 1/33,500 to 2 Seconds
Video
Streaming Resolution 1920 x 1080 at 30 fps
Supported Video Compression H.264, H.265, MJPEG
Multi-View Streaming Yes
Automatic Gain Control Yes
Audio
1- or 2-Way Audio One-Way
Audio Formats AAC-LC, G.711, G.726, LPCM, Opus
Built-In Mic Yes
External Audio Input 3.5 mm
Networking
Security Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection, User Access Log
Supported Protocols ARP, Bonjour, CIFS/SMB, DHCP, DNS, DynDNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, LLDP, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SFTP, SMTP, SNMP v1/v2c/v3 (MIB-II), SOCKS, SRTP, SSH, SSL/TLS, TCP, UDP, UPnP, USGv6
System Integration
Application Programming Interface (API) Open API for Software Integration, Including VAPIX and AXIS Camera Application Platform
AXIS Guardian with One-Click Connection
ONVIF Profiles G, S, and T
Analytics Included
AXIS Video Motion Detection, Active Tampering Alarm

Supported
AXIS Camera Application Platform Enabling Installation of Third-Party Applications
Event Trigger Yes
Event Action Recording, Notification, Alarm
Data Streaming Yes
Built-In Installation Aids Pixel Counter
Environmental
Operating Temperature -4 to 122°F / -20 to 50°C
Storage Temperature -40 to 149°F / -40 to 65°C
Operating Humidity 10 to 85%
General
Memory 512 MB RAM / 512 MB Flash
Media/Memory Card Slot Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum]
Pan/Tilt None
I/O Connections 1 x RJ45
1 x Power
1 x 4-Pin Terminal Block
1 x 2-Pin Terminal Block
Video Management Software AXIS Companion
AXIS Camera Station
Video Management Software from Axis Application Development Partners
Internal Storage None
External Storage Options NAS
Power Source DC, PoE 802.3af (15 W), PoE 802.3at (30 W)
Power Consumption DC: 3.8 W
PoE: 4.1 W
Material of Construction Polymer
Dimensions H: 1.8 x W: 2.8 x L: 5.8" / H: 46.0 x W: 70.0 x L: 148.0 mm
Weight 0.45 lb / 205 g
ModelDescriptionPriceStock
01768-001 M1135 Network Camera, HDTV 1080p, H.265, PoE, 3 - 10.5mm VF Lens $848.38
Call
Add to Cart
Product Accessories
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document M1135 Datasheet.pdf 268KB Download
PDF Document M1135 User Manual.pdf 521KB Download
