Camera | |
Sensor | 2 MP 1/2.8" CMOS |
Focal Length | 4.3 to 137mm |
Maximum Aperture | f/1.4 to 4 |
Zoom | Optical: 32x |
Lens Field of View | Horizontal: 60 to 2.3° Vertical: 39 to 1.3° |
IR Cut Filter | Mechanical |
Day/Night | Yes |
Minimum Illumination | Color: 0.16 Lux B&W: 0 Lux |
Shutter Speed | 1/66,500 to 1 Seconds |
Video | |
Streaming Resolution | 1920 x 1080 at 60 fps |
Supported Video Compression | H.264, MJPEG |
Multi-View Streaming | Yes |
Audio | |
1- or 2-Way Audio | One-Way |
Audio Formats | AAC, G.711, G.726, LPCM, Opus |
Built-In Mic | No |
External Audio Input | 3.5 mm |
Networking | |
Security | Centralized Certificate Management, Digest Authentication, HTTPS, IEEE 802.1X, IP Address Filtering, Password Protection, User Access Log |
Supported Protocols | ARP, Bonjour, CIFS/SMB, DHCP, DNS, DynDNS, FTP, HTTP, ICMP, IGMP, IPv4/v6, LLDP, NTP, QoS Layer 3 DiffServ, RTCP, RTP, RTSP, SFTP, SMTP, SNMP v1/v2c/v3 (MIB-II), SOCKS, SRTP, SSH, SSL/TLS, TCP, UDP, UPnP |
System Integration | |
Application Programming Interface (API) | Open API for Software Integration, Including VAPIX & AXIS Camera Application Platform AXIS Video Hosting System (AVHS) with One-Click Connection ONVIF Profiles S & G |
Analytics | Included: AXIS Video Motion Detection, AXIS Fence Guard, AXIS Loitering Guard, AXIS Motion Guard, Active Tampering Alarm, Gatekeeper Supported: AXIS Perimeter Defender, AXIS Cross Line Detection, AXIS Camera Application Platform for Third-Party Applications |
Event Trigger | Yes |
Event Action | Recording, Notification, Alarm |
Data Streaming | Yes |
Built-In Installation Aids | Remote Zoom, Pixel Counter, Leveling Assistant, Autorotation |
Environmental | |
Operating Temperature | -40 to 140°F / -40 to 60°C |
Storage Temperature | -40 to 149°F / -40 to 65°C |
Operating Humidity | 10 to 100% |
IP Rating | IP67 |
IK Rating | IK08 |
General | |
Memory | 1024 MB RAM / 512 MB Flash |
Media/Memory Card Slot | Single Slot: microSD/microSDHC/microSDXC [512 GB Maximum] |
Pan/Tilt | None |
I/O Connections | 1 x RJ45 1 x Power 1 x Uncrimped Ethernet Terminus 1 x 4-Pin Terminal Block |
IR Illuminators | 850 nm |
IR Range | 262.47' / 80 m |
Video Management Software | AXIS Companion AXIS Camera Station VMS from Axis' Application Development Partners |
Internal Storage | None |
External Storage Options | NAS |
Power Source | AC, DC, PoE 802.3af (15 W), PoE 802.3at (30 W) |
Power Consumption | 7.7 W |
Material of Construction | Aluminum |
Dimensions | ø: 5.8 x L: 15.2" / ø: 147.0 x L: 386.0 mm |
Weight | 5.29 lb / 2.4 kg |
Model | Description | Price | Stock | |
---|---|---|---|---|
01161-001 | Q1785-LE Network Camera, HDTV 1080p, 80m IR, Zipstream, WDR, PoE, 4.3 - 137mm | $2,426.88 | Add to Cart |
Filename | Size | ||
---|---|---|---|
![]() |
Q17 Series User manual.pdf | 1MB | Download |
![]() |
Q1785LE Data Sheet.pdf | 398KB | Download |
