Hikvision DS-2CD2T66G2-2I/ 4I
from $299.34 (incl. GST)
POSMarket SKU: Z14320
This model is available in 6 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.
6MP Outdoor AcuSense Gen 2 Bullet Camera
Product Overview
The Hikvision DS-2CD2T66G2-2I also known to be called HIK-2CD2T66G22I is a 6MP outdoor AcuSense gen 2 bullet camera. Empowered by deep learning algorithms, Hikvision's AcuSense technology can distinguish people and vehicles from other moving objects, such as falling leaves or small animals. While originally created with the purpose of preventing false alarms, AcuSense technology offers users several other key benefits such as advanced analytics, active deterrence and timely alerts.
The most paramount feature with the AcuSense gen 2 cameras is the analytic alert which will generate alarm events that are searchable when reviewing recorded footage for specific incidents. This saves many man hours of wasted time reviewing irrelevant video trying to identify an event, saving the end customer time and money.
Features
The most paramount feature with the AcuSense gen 2 cameras is the analytic alert which will generate alarm events that are searchable when reviewing recorded footage for specific incidents. This saves many man hours of wasted time reviewing irrelevant video trying to identify an event, saving the end customer time and money.
Features
- High quality imaging with 6 MP resolution
- Excellent low-light performance with powered-by-DarkFighter technology
- Efficient H.265+ compression technology
- Clear imaging against strong back light due to 120 dB true WDR technology
- Focus on human and vehicle targets classification based on deep learning
- Water and dust resistant (IP67)
Product Specifications
| Camera | |
| Image Sensor | 1/2.4" Progressive Scan CMOS |
| Min. Illumination Color: | 0.003 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Yes |
| Wide Dynamic Range | 120 dB |
| P/N | P/N |
| Day & Night | IR cut filter |
| Angle Adjustment Pan: | 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens | |
| Lens Type | Fixed focal lens, 2.8, 4, and 6 mm optional |
| Focal Length & FOV | |
| 2.8 mm | horizontal FOV 105.1°, vertical FOV 53.4°, diagonal FOV 128.6° |
| 4 mm | horizontal FOV 83.9°, vertical FOV 44.5°, diagonal FOV 100.8° |
| 6 mm | horizontal FOV 47.5°, vertical FOV 26°, diagonal FOV 54.5° |
| Iris Type | Fixed |
| Aperture | F1.6 |
| Lens Mount | M12 |
| DORI | |
| 2.8 mm: | D: 78.6 m, O: 31.2 m, R: 15.7 m, I: 7.9 m |
| 4 mm: | D: 95.6 m, O: 37.9 m, R: 19.1 m, I: 9.6 m |
| 6 mm: | D: 160.0 m, O: 63.5 m, R: 32.0 m, I: 16.0 m |
| Illuminator | |
| Supplement Light Type | IR |
| Smart Supplement Light | Yes |
| IR Range | |
| -2I: | up to 60 m |
| -4I: | up to 80 m |
| IR Wavelength | 850 nm |
| Video Compression | |
| Main stream: | H.265/H.264/H.264+/H.265+ |
| Sub-stream: | H.265/H.264/MJPEG |
| Third stream: | H.265/H.264 *Third stream is supported under certain settings. |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| H.264 Type | Baseline Profile/Main Profile/High Profile |
| H.265 Type | Main Profile |
| H.264+ | Main stream supports |
| H.265+ | Main stream supports |
| Bit Rate Control | CBR/VBR |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding |
| Region of Interest (ROI) | 1 fixed region for main stream and sub-stream |
| Image | |
| Image Parameters Switch | Yes |
| SNR | ≥ 52 dB |
| Target Cropping | Yes |
| Day/Night Switch | Day, Night, Auto, Schedule |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser Event |
| Basic Event | Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event | Scene change detection |
| Deep Learning Function | |
| Face Capture | Yes |
| Perimeter Protection | Line crossing detection, intrusion detection, region entrance detection, region exiting detection Supports human and vehicle targets classification General |
| Power Supply | 12 VDC +/- 25%, reverse polarity protection PoE: 802.3af, Class 3 |
| Power Consumption and Current | |
| -2I: | 12 VDC, 0.63 A, max. 7.5 W PoE (802.3af, 36 V to 57 V), 0.25 A to 0.16 A, max. 9W |
| -4I: | 12 VDC, 0.88 A, max. 10.5 W PoE (802.3af, 36 V to 57 V), 0.34 A to 0.21 A, max. 12 W |
| Approval | Protection IP67 (IEC 60529-2013) |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| DS-2CD2T66G2-4I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 80m IR, IP67, 2.8mm | $310.89 | Add to Cart | |
| DS-2CD2T66G2-4I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 80m IR, IP67, 4mm | $310.89 | Add to Cart | |
| DS-2CD2T66G2-4I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 80m IR, IP67, 6mm | $310.89 | Add to Cart | |
| DS-2CD2T66G2-2I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 60m IR, IP67, 2.8mm | $299.34 | Add to Cart | |
| DS-2CD2T66G2-2I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 60m IR, IP67, 4mm | $299.34 | Add to Cart | |
| DS-2CD2T66G2-2I | Hikvision 6MP Outdoor AcuSense Gen 2 Bullet Camera, H.265, WDR, 50m IR, IP67, 6mm | $299.34 | Add to Cart |
| Model | Description | Prices From | |
|---|---|---|---|
| Hikvision DS-1280ZJ-S | Junction Box with Gland, white or black | $40.43 | View Product |
| Hikvision DS-1260ZJ | Junction Box | $26.57 | View Product |
| Hikvision HS-TF-H1I | MicroSD Card for Surveillance | $50.82 | View Product |
| Hikvision DS-1276ZJ | Corner Mount, Bracket | $31.19 | View Product |
| Hikvision DS-1275ZJ-SUS | Horizontal Pole Mount | $58.91 | View Product |
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
| Filename | Size | ||
|---|---|---|---|
 |
DS2CD2T66G22I_4I Datasheet.pdf | 1015KB | Download |
|
DS2CD2T66G22I_4I User Manual.PDF | 11MB | Download |
