Hikvision DS-2CD5146G0-IZS

$812.35 (incl. GST)

POSMarket SKU: Z14143

DS-2CD5146G0-IZS: 4MP Indoor Darkfighter Dome Camera, 140dB ,WDR, IR, VCA, 30fps, 2.8-12mm

4MP Indoor Darkfighter Dome Camera.

Product Rating
Product Overview
Part of Hikvision's enterprise range of network cameras, the DS-2CD5146G0-IZS or HIK-2CD5146G0IZS is an indoor dome camera that produces exceptional 4MP high-resolution video. Powered by Darkfighter and Lightfighter technology, this camera can produce clear and crisp images in environments with extreme background lighting or in ultra-low light situations. The HIK-2CD5146G0IZS includes an ideal combination of smart features for its affordable price such as 140dB true wide dynamic range (WDR), image sensor technology, a high definition image processing chipset, audio/alarm IO and smart video content analytics (VCA). Additionally, this camera supports H.265 and H.265+ intelligent video compression, which reduces bandwidth/storage requirements by up to 50 percent and 80 percent, respectively. For the best performance, use of the DarkEye Lens (HIK-HV0733D6MP) is recommended.

Features
  • 1/1.8 inch progressive scan CMOS
  • 2560 x 1440 at 30fps
  • Colour: 0.002 lux at (F1.2, AGC ON)
  • 2.8-12mm motorised varifocal lens
  • H.265, H.265+, H.264+, H.264
  • 140dB wide dynamic range (WDR)
  • Up to 30m IR
  • Video content analytics (VCA) including face detection and object counting
  • 5 defined streams and up to 5 custom streams supported
  • Supports on-board storage up to 256 GB
  • IK10 rating
  • 12VDC or PoE
Product Specifications
CAMERA
Image Sensor 1/1.8" Progressive Scan CMOS
Min. Illumination Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR
Shutter Speed 1 s to 1/100,000 s
Slow Shutter Yes
Day & Night IR Cut Filter
Digital Noise Reduction 3D DNR
WDR 140 dB
Angle Adjustment Pan: 0°to 355°, tilt: 0°to 75°, rotate: 0°to 355°
LENS
Focal length 2.8 to 12 mm
Aperture F1.2
Focus Auto, semi-auto, manual
FOV 2.8 to 12 mm, horizontal FOV 102° to 38°, vertical FOV 53.0° to 21.2°, diagonal FOV 122.2° to 45°
Lens Mount Integrated
IR
IR Range Up to 30 m
Wavelength 850 nm
Max. Resolution 2560 x 1440
Main Stream
50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 30fps (2560 × 1440, 1920 × 1080, 1280 × 720)
Sub Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 576, 640 × 480)
Third Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
Fourth Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480)
Fifth Stream
50Hz: 25fps (704 × 576, 640 × 480)
60Hz: 30fps (704 × 576, 640 × 480)
Custom Stream
50Hz: 25fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60Hz: 30fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
Image Enhancement BLC, HLC, Defog, EIS
Image Setting Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
Target Cropping Yes
SVC H.264 and H.265 encoding
Day/Night Switch Day/Night/Auto/Schedule/Triggered by Alarm In
Picture Overlay LOGO picture can be overlaid on video with 128 x 128 24bit bmp format
ModelDescriptionPriceStock
DS-2CD5146G0-IZS 4MP Indoor Darkfighter Dome Camera, 140dB ,WDR, IR, VCA, 30fps, 2.8-12mm $812.35
Call
 Add to Cart
ModelDescriptionPrices From
Hikvision DS-1271ZJ-130-TRL Pendant Mount Bracket $69.30 View Product
Hikvision DS-1273ZJ-130B Turret Wall Mount Bracket $46.20 View Product
Hikvision DS-1273ZJ-130 Wall Mount Bracket to suit 7xx and 41xx Dome Cameras $40.43 View Product
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document DS-2CD5146G0-IZS Datasheet 1MB Download
PDF Document DS2CD5146G0IZS Quick Start Guide.pdf 3MB Download
PDF Document DS2CD5146G0IZS User Manual.pdf 5MB Download
Product Videos
No videos found for this product.

Please contact our team for more information using the 'Ask an Expert' form or call us on 1300 737 998.
