Evolis Quantum

$CALL

POSMarket SKU: Z5492

EQuant: Quantum2 Large Volume Card Printer

The power of an industrial card printer with the flexibility of a desktop printer. The Quantum card printer is the solution for printing and encoding cards in large volumes. With a printing speed of more than 1000 cards per hour and dual sided printing it is the perfect solution for centralized production of cards in large quantities.

Product Rating

Product Overview

The Quantum, a dual-sided plastic card printer, is designed specifically for high-volume badge personalization.
With a total printing capacity of 1000 cards in full colour, the Quantum is the ideal solution for markets that require volume and capacity: service bureau, access control, time attendance, healthcare, telecommunications.

Features
  • Increased productivity
    Thanks to its feed tray and stacker with a capacity of 500 cards each, the Quantum printer can deliver more than 1000 cards per hour in monochrome and more than 150 cards in color. With the reversible encoding module that is independent from the print module, the cards are encoded and printed in a single pass.

  • Ease of use

    Quantum was designed to simplify and speed up every day operation and maintenance:
    • Load and retrieve the cards without removing the storage trays (on unlocked version).
    • Check the card level at a glance
    • LCD display showing printer status and consumable levels

  • Economic solution
    Quantum can handle large volumes of cards with very high print quality, providing a very economical alternative to industrial card printers. You can produce your cards yourself instead of having to go to an outside provider.

  • Multiple encoding
    The printer comes standard with a removable encoding module for combined encoding of magnetic stripes, contact smart cards and contactless cards. Quantum can be customized on-site to meet your specific needs as they evolve.

  • Quantum is also available in a secure version
    Quantum has an optional central locking feature to protect access to consumables (cards and ribbon) and to the encoding module, to make your card issuance system safe and secure.

  • Lasting investment
    Quantum's components, including its metal frame, were selected to ensure durability and reliability over time. The sealed cover as well as the cleaning process effectively protect against dust and dirt. Thanks to Quantum's top quality design, you can be sure that your investment will last.

  • Peace of mind guaranteed
    With our standard warranty covering 500,000 insertions the first year and our optional warranty extensions, you don't have to worry about a thing.

Product Specifications

General Features
  • 2 configurations:
    Standard version without locking mechanism
    Version with centralized locking system
  • Direct-to-card dye-sublimation/Resin thermal transfer
  • Single-sided and dual-sided printing module
  • Edge-to-edge printing
  • 300 dpi print head (11.8 dots/mm)
  • 16MB memory (RAM) allowing two card storages (front & back)
  • Interchangeable input and output hoppers, capacity of 500 cards each (0.76 mm - 30 mil)
  • Aluminum body, black plastic covers
Printing Performance
  • Single side:
    Color (YMCKO): 150 cards/hour
    Monochrome: 1000 cards/hour
  • Dual side:
    Color (YMCKO-K): 115 cards/hour
    Monochrome: 320 cards/hour
Additional Pack Offer
  • Quantum Production Pack: 1 detachable card hopper with short door, 2 cleaning rollers, 1 cleaning kit
  • Quantum Backup Pack: 1 print head, 1 reversible encoding module, 1 detachable card hopper with short door
Interfaces
  • USB (1.0, 1.1, 2.0, 3.0), cable supplied
  • Ethernet TCP-IP 10BaseT, 100BaseT (Traffic Led)
Safety
  • Centralized locking system (optional) to secure access to the whole system (incl. cards and ribbon)
Display
  • 2-line LCD display
  • Status LED for printer and encoding unit monitoring
Additional encoding modules
  • Reversible upper and lower encoding unit for magnetic stripes and contact smart cards (patented)
  • HiCo/LoCo magnetic stripe encoder ISO 7811 or JIS2
  • Smart contact station ISO 7816-2
  • Connecting panel and mounting area for users own integration of encoding units
  • Encoding options:
    Smart encoding unit PC/SC, EMV 2000-1
    Contactless encoding unit - ISO14443A & B, Mifare, DesFire, HID iCLASS
    Other types upon request
Card management and specifications
  • Detachable and interchangeable card input feeder and output stacker with 500 cards capacity (0.76 mm - 30 mil)
  • Reject hopper for defective cards with a capacity of 20 cards (0,76mm - 30mil)
  • Detachable hopper (long or short doors) with a capacity of 500 cards (0.76 mm - 30 mil) as an option
  • Card types:
    PVC cards
    Composite PVC cards
    PET cards
    ABS cards
    Special varnished cards
  • Card format: ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)
  • Thickness: 0.76mm to 1mm (30 to 40 mil)
Software
  • Delivered with cardPresso XXS for designing and editing badges:
    Internal database (unlimited records)
    Windows (from XP onwards) and Mac OS X
    Windows (32/64 bits): XP SP3, Vista, W7, W8, W10
    Mac OS X v10.4 and higher (upon request)
    Linux (upon request)
Certifications and statement of compliance
  • RoHS
  • CE, FCC, VCCI, ICES
  • EAC
Size and weight
  • Size (H x W x D):
      Without hoppers: 215 x 300 x 850 mm
      With hoppers: 567 x 300 x 850 mm
  • Weight: 21.7 kg (18.3 kg without hoppers)
Warranty
  • 1-year warranty (printer and print head) limited to 500,000 passes)
  • Warranty extension available as an option
ModelDescriptionPriceStock
EQuant Quantum2 Large Volume Card Printer $CALL
Call
ModelDescriptionPrices From
POSMarket Plastic Cards Plain CR80 size 30mil cards, Pack of 500 $33.88 View Product
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document Quantum Brochure User Guide 2MB Download
PDF Document Quantum Brochure 421KB Download

Product Videos

Quantum plastic card printer presentation
