TSL 2173
from $1,870.00 (incl. GST)
POSMarket SKU: Z8855
This model is available in 4 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.
Bluetooth LF/HF RFID Reader.
Product Overview
The 2173 is a Bluetooth wearable HF/LF RFID reader. Compatible with any Bluetooth enabled smartphone, tablet or enterprise mobile device, the 2173 adds RFID capture at the tips of your fingers. Being a wearable device, it's perfect for warehouses or environments where full use of both hands is required.
The 2173 Bluetooth LF/HF RFID Reader enables a Bluetooth host device to read and write to a wide variety of Low Frequency and High Frequency RFID transponders. The optional 2D Imager version can also capture 1D and 2D barcodes.
Scanned information can be 'typed' by the Reader into any application on the host device using the Bluetooth HID keyboard mode. Alternatively, the Reader can be commanded from an app on the host device. As the 2173 Reader uses the existing TSL ASCII 2 Protocol, developers can take advantage of the comprehensive, free SDKs provided by TSL to develop in Xamarin, Java, Objective C or .NET.
Multi-Band RFID Reading and Writing
Combined LF RFID, HF RFID and NFC reading and writing in an incredibly compact and lightweight device.
Multi-ISO RFID
Supports multiple ISO industry standards including ISO15693, ISO14443(A/B) and ISO18092 ECMA-340 (NFC).
Batch Data Collection
Removable high capacity Micro SD data card and real time clock for extended batch data collection with time stamp independent of the host connection.
OS Independence
The reader is compatible with Android, iOS and Windows.
High Performance Barcode Scanning
Integrated 2D imaging engine provides class leading barcode scan performance via its unique patent pending fast pulse illumination which delivers outstanding motion tolerance and class leading 1D and 2D data capture.
The 2173 Bluetooth LF/HF RFID Reader enables a Bluetooth host device to read and write to a wide variety of Low Frequency and High Frequency RFID transponders. The optional 2D Imager version can also capture 1D and 2D barcodes.
Scanned information can be 'typed' by the Reader into any application on the host device using the Bluetooth HID keyboard mode. Alternatively, the Reader can be commanded from an app on the host device. As the 2173 Reader uses the existing TSL ASCII 2 Protocol, developers can take advantage of the comprehensive, free SDKs provided by TSL to develop in Xamarin, Java, Objective C or .NET.
Multi-Band RFID Reading and Writing
Combined LF RFID, HF RFID and NFC reading and writing in an incredibly compact and lightweight device.
Multi-ISO RFID
Supports multiple ISO industry standards including ISO15693, ISO14443(A/B) and ISO18092 ECMA-340 (NFC).
Batch Data Collection
Removable high capacity Micro SD data card and real time clock for extended batch data collection with time stamp independent of the host connection.
OS Independence
The reader is compatible with Android, iOS and Windows.
High Performance Barcode Scanning
Integrated 2D imaging engine provides class leading barcode scan performance via its unique patent pending fast pulse illumination which delivers outstanding motion tolerance and class leading 1D and 2D data capture.
Product Specifications
| Performance Characteristics | |
| Communication protocols | TSL ASCII 2.0 parameterised command set |
| Memory | Supports up to 32 GB Micro SD/SDHC card |
| Frequency Range | 125/134.2 kHz (LF) / 13.56 MHz (HF) |
| Read Distance | Up to 100 mm / 4" (dependent on transponder type) |
| RF Transmission Speed | HF Air: up to 848 kbit/s |
| Standards supported | ISO14443A ISO14443B ISO18092 ECMA-340 (NFC) ISO15693 plus many 125 kHz, 134.2 kHz standards |
| Barcode module | Optional 2D imager |
| Compatible Host devices(Bluetooth) | Serial Port Profile (SPP) Human Interface Device (HID) profile (Android, iOS, Linux, Mac, Windows) |
| Physical and Environmental Characteristics | |
| Drop Spec | Multiple drops to concrete: 4 ft./1.2 m ambient 3ft / 0.9m across the operating temperature range |
| Tumble | 500 x 0.5 metre tumbles at room temperature (1,000 cycles) |
| Environmental Sealing | IP54 |
| Dimensions (LxWxH) | 10.2 cm x 5.5 cm x 5.6 cm |
| Weight (inc battery) | 157g |
| User input | Two Trigger buttons |
| User feedback | Speaker Vibration motor Three LEDs |
| Power | Removable Rechargeable 3.7 volt Lithium Polymer 1130 mAh battery pack 4.2 watt hrs |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| 2173-BT-LF-HF-IMG-PI | TSL 2173 Wearable Bluetooth RFID Reader. LF/HF with Proxy & iclass, 2D scanner | $3,086.88 | Add to Cart | |
| 2173-BT-LF-HF-IMG | TSL 2173 Wearable Bluetooth RFID Reader. LF/HF, 2D Scanner | $2,695.00 | Add to Cart | |
| 2173-BT-LF-HF-A1-PI | TSL 2173 Wearable Bluetooth RFID Reader. LF/HF with Proxy & iclass | $2,227.50 | Add to Cart | |
| 2173-BT-LF-HF-A1 | TSL 2173 Wearable Bluetooth RFID Reader. LF/HF | $1,870.00 | Add to Cart |
Product Accessories
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
| Filename | Size | ||
|---|---|---|---|
 |
TSL 2173 User Guide | 2MB | Download |
|
TSL 2173 brochure | 716KB | Download |
