TSC TTP-368MT
$CALL
POSMarket SKU: Z5272
99-141A002-00LF: TTP-368MT Industrial label printer. Thermal transfer, 6" print width, 300dpi, USB/Serial/Parallel/Ethernet interface
The TTP-368MT Series is a 6.6" Wide Thermal Transfer Industrial label printer, perfect for printing wide format labels. It has been updated with new high speed electronics, boosting the print speed to 8" per second whilst also improving the print quality. It comes standard with a 300dpi print head, large colour LCD touch display and Ethernet/USB/Serial/Parallel interfaces.
Product Overview
The TTP-368MT Series of 6.6 inch wide industrial thermal transfer printers has been newly updated with high speed electronics that allow for faster print speeds combined with improved print quality. The TTP-368MT Series is specifically designed for applications that require high quality wide format thermal transfer or direct thermal labels.
The TTP-368MT standard features include a large color LCD touch display, built-in Ethernet, USB 2.0, USB host, parallel and serial communications as well as a an SD FLASH memory card reader that allows users to inexpensively add up to 32 GB of additional storage memory for a wide variety of fonts and graphics.
Improved Print Quality
The TTP-368MT Series features the best print quality TSC has ever offered in a wide web printer thanks to new printhead technology combined with faster processors and upgraded firmware. We call our enhanced print quality "Thermal Smart Control" which tracks and precisely calculates the duration that each pixel needs to be heated to provide accurate, crisp and clear labels every time, whether you are printing one label at a time or thousands of labels in a batch.
High Speed Performance, more memory
Compared to its predecessor, the TTP-368MT is faster, performing at up to 8 inches per second and has an increased memory of 512 MB Flash and 256 MB SDRAM.
A Colorful Choice
The new TTP-368MT Series comes with a high-contrast 4.3" color touch LCD panel with 6 button control user friendly design for simple printer set up and job status.
Multiple Resolutions for a wide range of applications
There are two models available with the new TTP-368MT Series. The TTP-2610MT features 203 dpi resolution at speeds up to twelve inches per second, TTP-368MT offers 300 dpi resolution at speeds up to eight inches per second.
Powerful TSPL-EZ printer programming language
TTP-368MT Series features the TSPL-EZ printer-control language, a fully compatible set of standard industry emulations, including Line Mode, Eltron and Zebra languages and will work in many IT environments including Oracle, SAP, Unix, AS/400, Windows, Stand Alone, and many more.
The TTP-368MT standard features include a large color LCD touch display, built-in Ethernet, USB 2.0, USB host, parallel and serial communications as well as a an SD FLASH memory card reader that allows users to inexpensively add up to 32 GB of additional storage memory for a wide variety of fonts and graphics.
Improved Print Quality
The TTP-368MT Series features the best print quality TSC has ever offered in a wide web printer thanks to new printhead technology combined with faster processors and upgraded firmware. We call our enhanced print quality "Thermal Smart Control" which tracks and precisely calculates the duration that each pixel needs to be heated to provide accurate, crisp and clear labels every time, whether you are printing one label at a time or thousands of labels in a batch.
High Speed Performance, more memory
Compared to its predecessor, the TTP-368MT is faster, performing at up to 8 inches per second and has an increased memory of 512 MB Flash and 256 MB SDRAM.
A Colorful Choice
The new TTP-368MT Series comes with a high-contrast 4.3" color touch LCD panel with 6 button control user friendly design for simple printer set up and job status.
Multiple Resolutions for a wide range of applications
There are two models available with the new TTP-368MT Series. The TTP-2610MT features 203 dpi resolution at speeds up to twelve inches per second, TTP-368MT offers 300 dpi resolution at speeds up to eight inches per second.
Powerful TSPL-EZ printer programming language
TTP-368MT Series features the TSPL-EZ printer-control language, a fully compatible set of standard industry emulations, including Line Mode, Eltron and Zebra languages and will work in many IT environments including Oracle, SAP, Unix, AS/400, Windows, Stand Alone, and many more.
Product Specifications
| Resolution | 12 dots/mm (300 DPI) |
| Max. print speed | 254 mm/second |
| Max. print width | 168 mm |
| Max. print length | 6,604 mm |
| Printing method | Thermal Transfer & Direct Thermal |
| LCD/LED | 16 bits Color 480 x 272 pixels with back lights Resistive Touch Screen |
| SDRAM | 256 MB |
| Flash | 512 MB |
| Extension | SD Flash memory card reader for Flash memory expansion, up to 32 GB |
| Ribbon capacity | 450 meter long, max. OD 81 mm, 1" core (Ink coated outside/inside) |
| Ribbon width | 50.8 mm - 178 mm |
| Media type | Continuous, die-cut, fan-fold, tag, notched, black mark (outside wound) |
| Media width | 50.8 - 172.7 mm |
| Media thickness | 0.06 - 0.254 mm |
| Media core diameter | 76.2 mm |
| Media length | 10 - 14,732 mm |
| Media roll capacity | 208.3 mm OD |
| Interface | USB 2.0 RS-232 Parallel Ethernet 10/100 Mbps USB Host |
| Interface Options | GPIO 802.11 a/b/g/n Wi-Fi |
| Software support | Oracle, WHQL 8.1, MFi, Windows, Linux, MAC X.10, Microsoft SQL Server, BarTender, Nice Label |
| Dimensions | 355 mm (W) x 337 mm (H) x 520 mm (D) |
| Weight | 23 kg |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| 99-141A002-00LF | TTP-368MT Industrial label printer. Thermal transfer, 6" print width, 300dpi, USB/Serial/Parallel/Ethernet interface | $CALL |
| Model | Description | Prices From | |
|---|---|---|---|
| POSMarket Label Rolls | Various label rolls to suit thermal and ink roller printers. | $3.73 | View Product |
| TSC SLOT-IN 802.11 A B G N WIRELESS MODULE | TSC Slot-In 802.11 A/B/G/N Wireless Module For Industrial Printers | $561.00 | View Product |
| TSC TTP-2410MT MU HEAVY DUTY CUTTER | Heavy Duty Cutter, Rotary Cutter, for labels up to 300 g/m2, fits for: TTP-2410MT Series | $1,483.35 | View Product |
| TSC TTP-2610MT 368MT Heavy Duty Cutter Module | TTP-2610MT/368MT Heavy Duty Cutter Module. Cutter high resistance settings for: TTP-2610MT | $1,476.75 | View Product |
| TSC TTP-2610MT 368MT PEEL OFF MODULE | TTP-2610MT/368MT Peel Off Module | $651.75 | View Product |
| TSC 98-0410008-01LF | TSC TTP-366M Replacement Print Head | $907.50 | View Product |
| Seagull Scientific BARTENDER AUTO | With BarTender, you get improved design quality, reduced label maintenance, maximized printing performance and the ability to remain compliant with changing standards. | $3.47 | View Product |
| Seagull Scientific BARTENDER ENT - APP | BarTender Enterprise - Application | $1.80 | View Product |
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
| Filename | Size | ||
|---|---|---|---|
 |
TSC TTP-2610MTTTP-368MT Brochure | 1MB | Download |
Product Videos
TSC TTP-2610MT368MT Loading the media
TSC TTP-2610MT368MT Loading the ribbon
