ELO 2203LM

from $2,124.38 (incl. GST)

POSMarket SKU: Z7555

This model is available in 3 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.

The Elo 2203LM 22-inch touchscreen monitor for healthcare delivers a professional-grade interactive solution with ELO's industry-leading TouchPro PCAP technology featuring edge-to-edge glass and enabling up to 10 simultaneous touches.

Product Rating
Product Overview
The clear glass touchscreen provides exceptional image clarity, resolution, and light transmission for vivid images and details. Available in either black or white housings, the feature rich touchscreen monitor is equipped with dual built-in speakers and VGA and HDMI video connectors - and backed by a three-year warranty. The 03-Series is designed for healthcare with their compact form factor and clean design combined with IEC60601-1 4th edition and IP54 compliance.

A wide range of peripherals and accessories can be used with the 2203LM including handles to allow physicians to move the monitor with ease during patient visits and privacy screens for HIPAA compliance. And, with the integrated USB 2.0 hub, third party peripherals can be easily added such as a fingerprint reader or barcode scanner.

  • Touchscreen is compatible with use of finger, glove and stylus
  • Multiple mounting options including - stand mount, wall mount and pole mount.
Product Specifications

Enclosure Colour

White or Black

Touch Technology & Capacity

PCAP (TouchPro Projected Capacitive) - 10 Touch

Diagonal Size

21.5'" diagonal, Active matrix TFT LCD (LED)

Aspect Ratio

16:9

Resolution

1920 x 1080 @ 50, 60Hz

Number of Colors

16.7 million

Brightness (typical)

LCD Panel: 250 nits
TouchPro PCAP: 225 nits

Response Time-total (typical)

25 msec

Contrast Ratio

1000:1

Touch Interface

USB

Surface Treatment

Anti-glare

I/O Ports

VGA
HDMI
Combo Jack
DC jack
USB Type B
USB 2.0 Type A
4x Micro USB

Speakers

Two x 2W internal speakers

Input Video Format

VGA (VGA DE-15 (DB-15) Male connecter cable included)
HDMI (HDMI cable included)

Input Video Frequency

Horizontal: 30 - 82KHz
Vertical: 50 - 75Hz

Warranty

3-year
ModelDescriptionPriceStock
E350428 2203LM White 22" Wide screen, TouchPro PCAP 10 Touch screen, VGA/HDMI Video interface, USB touch controller $2,316.88
Call
 Add to Cart
E350428 2203LM White 22" Wide screen, TouchPro PCAP 10 Touch screen, VGA/HDMI Video interface, USB touch controller $2,316.88
Call
 Add to Cart
E124347 2203LM Black 22" Wide screen, TouchPro PCAP 10 Touch screen, VGA/HDMI Video interface, USB touch controller $2,124.38
Call
 Add to Cart
ModelDescriptionPrices From
Atdec Spacedec Direct Wall Mount The black Spacedec SD-WD Wall Mount from Atdec is a low-profile, robust mount created to cope with demanding commercial environments and a heavy workload, where quick installation and flexible screen positioning are required. $108.63 View Product
Ergonomic Solutions SpacePole VESA Bracket for 15 inch Screen Screen add-on bracket for VESA w/ MultiGrip for 15 inch screen. $99.69 View Product
Ergonomic Solutions SpacePole VESA Bracket for 22 inch Screen Screen add-on bracket for VESA w/ MultiGrip for 22 inch Screen. $110.00 View Product
Ergonomic Solutions SpacePole 400mm Dual Screen Mount for Engage One Back-to-back screen mount solution, Engage One/VESA 400mm pole. $632.50 View Product
Ergonomic Solutions SpacePole VESA Pole Mount The classic SpacePole Screen Mount is probably the most used foundation in mounting POS systems. $CALL
Ergonomic Solutions Spacepole Essentials Standard Mount SpacePole Essentials is a product range appropriate for technology partners and end users alike. $254.38 View Product
Ergonomic Solutions SpacePole Back to Back VESA Pole Mount Back to back enables two screens to be fitted to one SpacePole. $508.75 View Product
Ergonomic Solutions SpacePole Swing Arm Pole Mount 200mm Our popular Swing Arm provides an ergonomic solution where peripherals or the screen itself is needed to swing between the operator and customer. $316.25 View Product
Ergonomic Solutions Spacepole Essentials 200mm Swing Arm Mount SpacePole Essentials is a product range appropriate for technology partners and end users alike. $302.50 View Product
Ergonomic Solutions SpacePole Height Adjustable VESA Pole Mount The Height Adjustable Arm is an ergonomically designed mounting solution that reduces the possibility of Repetitive Strain Injury (RSI), whilst assisting productivity at the workstation. $783.75 View Product
Ergotron Monitor Handle Kit Single monitor handle kit $99.69 View Product
Ergotron Dual Monitor and Handle Kit Convert a single-monitor mount so it holds two displays, and a handle is included to make repositioning of the screens easy. $226.88 View Product
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document ELO 2203LM brochure 641KB Download
