Dahua PFS3106-4ET-60

$94.53 (incl. GST)

POSMarket SKU: Z18231

DH-PFS3106-4ET-60: 4-Port PoE Switch (Unmanaged)

4-Port PoE Switch (Unmanaged)

Product Rating
Product Overview
The Dahua DH-PFS3106-4ET-60 is a layer two Hardened PoE Switch, which provides 4*10/100Mbps PoE ports, 1*100/1000 Mbps optical port and 1*10/100/1000Mbps Ethernet uplink port. With high level lightning protection and wide working temperature range makes it a better performance in outdoor or harsh environment.

The PoE 2.0 is specially designed for surveillance transmission. At present, the entire Dahua PoE switch series is fully upgraded to PoE2.0 that includes practical features such as PoE Watchdog, BT 90W (Red Port) and Long Distance PoE Transmission. These functions significantly enhance the utility of our switches in surveillance scenarios, making them more convenient to maintain.

  • Eight-Pin assignment PoE power supply
  • Intelligent PoE
  • Hi-PoE 60W (Orange Port)
  • PoE watchdog
  • 250 m long distance PoE transmission
  • Wide operating temperature: -30°C to +65°C (-22°F to +149°F)
Product Specifications
PFS3106-4ET-60
Part no DH-PFS3106-4ET-60
Ethernet Port 1*100/1000 Base-X
1*10/100/1000 Base-T
4*10/100 Base-T (PoE power supply)
PoE Power ConsumptionPort1≤60W, Port2-4≤30W, Total≤60W
PoE PIN Assignment1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
PoE Power ManagementSupport
PoE Protocol IEEE802.3af (PoE), IEEE802.3at (PoE+), Hi-PoE
Switching Capacity 6.8G
Packet Forwarding Rate 3.57Mpps
Packet Buffer Memory 1Mb
MAC Table Size 8K
Flow Control Enable by default
Application Humidity 5%~95%
Power DC 48~57V power adapter
Lightning Protection Common Mode 6KV
Differential Mode 4KV
ESD Protection Air Discharge 15KV
Contact Discharge 8KV
Working Temperature -30°C~65°C
Weight 440g
Dimension(WxDxH) 150mmx108mmx30mm
ModelDescriptionPriceStock
DH-PFS3106-4ET-60 4-Port PoE Switch (Unmanaged) $94.53
Call
 Add to Cart
Product Accessories
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document PFS31064ET60 Datasheet.pdf 696KB Download
PDF Document PFS31064ET60 User Manual.pdf 495KB Download
