Tensor MT-MCP2ISJFP100
POSMarket SKU: Z17065
7/0.20mm, 2x Twisted Pair, Screened, Jelly Filled Cable, 100m
Product Overview
Tensor has a wide range of quality security products designed and manufactured to meet Australian specifications. At Tensor Security, you will find a wide variety of Paradox alarm products, ranging from motion detectors and kits, to remotes and keypads.
Need help finding the right alarm system? Ask us about 7/0.20mm, 2x Twisted Pair, Screened, Jelly Filled Cable, 100m.
Our expert team has specialised training and experience to help find the right solution for your business.
Call 1300 737 998
Product Specifications
| Brand | Generic |
| Packaged Quantity | 1 Roll |
| Type | 7/0.25mm Tinned Copper Conductor |
| Pack Size | 500m |
| Applicable Standards | AS/ACIF S008 |
| Suitable Applications | Used as signal transmission and connection of checking appliances of distribution system, computer system. |
| ROHS Compliant | Yes |
| A-Tick (Yes/No) | yes |
| No. Pairs | 2 |
| AWG | 22 |
| Stranding (mm) | 7/0.25 |
| Area (mm2) | 0.34 |
| Diameter (mm) | 0.75 |
| Material | TC |
| Material | PP |
| Nominal Thickness (mm) | 0.2 |
| Nominal OD (mm) | 1.2 |
| AWG | 24 |
| Stranding | 7 |
| Area (mm2) | 0.22 |
| Diameter (mm) | 0.2 |
| Material | TC |
| Insulation - Elongation at BBA | >150% |
| Outer Sheath - Elongation at BBA | >400% |
| Max. Conductor DC Resistance @ 20 C | 55Ω/km |
| Min. Insulation Resistance @ 20 C | 1,000M OHMS.km |
| Voltage Test: Conductor to core | 1.5 kV ac/1min |
| Voltage Test: Core to sheath | 3.0 kV ac/1min |
| Operating Temp Range | -15 to 70 C |
| Max. Recommended Pulling Tension | 96N |
| Min Bend Radius (Install) | 50mm |
| Approximate Mass(kgs/100m) | 3.7kg/100m |
| Supply Information - Pack Type | Wooden Reel |
| Dimensions | W33 x H21.8cm |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| MT-MCP2ISJFP100 | 7/0.20mm, 2x Twisted Pair, Screened, Jelly Filled Cable, 100m | $208.86 | Add to Cart |
