Axis 5502-761

$483.45 (incl. GST)

POSMarket SKU: Z15149

5502-761: DC-Iris Lens to suit M111x, F1.5, CS Mount, 15-50mm VF Lens

Axis 3 MP Varifocal DC Auto-Iris Lens that offers greater flexibility for specific surveillance needs (15 to 50mm)

Product Rating
Product Overview
The Axis 3 MP Varifocal DC Auto-Iris Lens / AXIS-5502-761 is a DC-iris lens designed for 1/3" to 1/4" format megapixel cameras. With an aspherical lens, low-dispersion glass, and incorporated advanced optical design technology, this lens produces high-precision images from the image center to the margin areas, and exploits the full performance of a megapixel camera. This is the most suitable lens for high-quality image surveillance when using megapixel cameras, as well as lower resolution cameras.

FEATURES
  • Megapixel lens
  • CS-mount
  • Designed to maximise optical performance
  • Metal mount
Product Specifications
5502-761
Focal Length 15 to 50 mm (3.3x)
Iris Range F1.5 to T360 (equivalent to F360)
Operation Zoom / Focus: Manual
Iris: Auto (DC type)
Angle of View 1/3" (H x V): 18°08' x 13°34' (wide) / 5°35' x 4°12' (tele)
1/4" (H x V): 13°34' x 10°10' (wide) / 4°12' x 3°10' (tele)
Focusing Range		From front of the lens: Infinity to 2.62' (infinity to 0.8 m)
Object Dimensions at M.O.D. 1/3" (H x V): 10.66 x 7.95" (271 x 202 mm) (wide) / 3.42 x 2.59" (87 x 66 mm) (tele)
1/4" (H x V): 7.95 x 5.94" (202 x 151 mm) (wide)/ 2.59 x 1.92" (66 x 49 mm) (tele)
Back Focal Distance In air: 0.40" (10.03 mm)
Exit Pupil Position From image plane: -1.41" (-36 mm)
Mount CS
Coil Resistance Drive: 190 ohm
Damping: 500 ohm
Current Consumption 23 mA (maximum) at 4 VDC
Weight 2.11 oz (60 g)
ModelDescriptionPriceStock
5502-761 DC-Iris Lens to suit M111x, F1.5, CS Mount, 15-50mm VF Lens $483.45
Call
 Add to Cart
Product Accessories
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document Optional CSmount lenses Datasheet.pdf 576KB Download
