Posiflex DS-220

$1,014.75 (incl. GST)

POSMarket SKU: Z8246

DS220: Dock Station for MT-4308G4310G with 3 high speed dual band WIFI printer 2.4GHz5GHz 2T2R mode built-in 3 x USB2.0 1 x LAN 2 x DB9 RS232 1 x CR port tablet charging

DS series, Docking Station MT4308 4310G with dual ring Wifi printer

Product Rating
Product Overview
The DS-220 is the optional dock station for MT Series Retail Package (R). Once the MT Series tablet is docked with the DS-220, a traditional desktop POS is instantly at your disposal.

Features
  • With 3" WiFi (2.4 GHz/5.0 GHz, 2T2R mode) dual band thermal printer (200 mm/sec max.) built-in
  • USB x 3 + COM x 2 (DB9) + LAN + CR
  • Tablet charging
Product Specifications
Brand Posiflex
Description Dock Station
Model DS-220
Supported MT Series
Power Supply 12VDC/100W power adaptor
Wireless connectivity WIFI 802.11a/b/g/n 2.4G/5GHz, 2T2R dual band antenna
LED Indicator Power / Error / Paper-out / Wi-Fi
Button Power / Paper Feed / WiFi Reset / Cover Release
I/O Port DC-IN Power Jack / RJ11 Cash Drawer Port / RJ45 Giga LAN Port / DB-9 COM Port (x2) / USB 2.0 Port (x3)
Printing method Thermal Sensitive Line Dot Method
Effective printing width 58mm / 80mm (Max.)
Printing speed 200 mm / sec. (Max.)
Auto-cutter capability Partial cut / Full cut
Operating Condition 0°C ~ 40°C, 20% RH ~ 90% RH
Storage Condition -20°C - 60°C, 10%RH - 90% RH
Warranty 12 months
ModelDescriptionPriceStock
DS220 Dock Station for MT-4308G4310G with 3 high speed dual band WIFI printer 2.4GHz5GHz 2T2R mode built-in 3 x USB2.0 1 x LAN 2 x DB9 RS232 1 x CR port tablet charging $1,014.75
Call
 Add to Cart
Product Accessories
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document DS2xx User manual.pdf 1MB Download
