Epson TM-U220

from $452.87 (incl. GST)

POSMarket SKU: Z4569

This model is available in 5 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.

Epsons TM-U220 printers are compact, reliable and fast and offer all the easy-to-use features important to the retail restaurant and hospitality industries. The industry standard in kitchen Dot Matrix printers, there is a reason why these are used in almost every commercial kitchen for printing order dockets

Product Rating
Product Overview
Epson's TM-U220 impact printers are compact, reliable and optimized for high-speed throughput. They offer all the easy-to-use features important to the retail, restaurant and hospitality industries and two-color printing to highlight special offers, kitchen orders and impactful logos. In addition, the TM-U220 printers have been designed to be 100% compatible with existing systems that currently use a TM-U200 printer.
  • Drop-in paper loading
  • Easy to operate
  • Faster print speed
  • Flexible paper widths
  • Impactful logo printing in black
  • Three printer models
  • Two-color black and red printing
  • Two-year warranty
Product Specifications
PRINT METHOD9-pin, serial impact dot matrix
PRINT FONT 7 x 9 / 9 x 9
COLUMN CAPACITY 40 or 42 columns / 33 or 35 columns
CHARACTER SIZE 1.2(W) x 3.1 (H) mm / 1.6 (W) x 3.1 (H) mm
CHARACTER SET 95 Alphanumeric characters, 37 International characters, 128 x 12 Graphic characters Traditional / Simplified Chinese, Thai, Japanese, Korean
PRINT SPEED Approx. 4.7 LPS (40 columns, 16CPI) / Approx. 6 LPS (30 columns, 16 CPI)
DATA BUFFER 4 KB or 40 bytes
INTERFACE Serial (RS232), Parallel, USB or Ethernet/td>
PAPER DIMENSIONS 57.5 + 0.5, 69.5 + 0.5, 76mm 0.5mm x dia. 83.0mm (roll)
PAPER THICKNESS 0.06 to 0.085mm
COPY CAPABILITY One original and one copy
INKED RIBBON ERC-38 (black, black and red)
RIBBON LIFE Black: 3 x 106 characters B/R: 15 x 105 characters (black) 75 x 104 characters (red)
POWER SUPPLY AC adapter (included)
POWER CONSUMPTION Approx. 31 W average
D.K.D. FUNCTION 2 drivers
EMI STANDARDS VCCI class A, FCC class A, CE marking, AS / NZS 3548 class B
SAFETY STANDARDS UL, CSA, TV (EN60950)
POWER SUPPLY PS-180
ModelDescriptionPriceStock
C31C514676 TM-U220B. Auto cutter, USB interface, Dark Grey $487.03
< 10
 Add to Cart
C31C514452 TM-U220B Auto cutter, Serial interface, Black $590.76
Call
 Add to Cart
C31C514778 TM-U220B V3. Auto cutter, Ethernet interface, Dark Grey $537.63
Call
 Add to Cart
C31C514252 TM-U220B. Auto cutter, Serial interface, Dark Grey $452.87
Call
 Add to Cart
C31C517252 TM-U220B. Auto cutter, Parallel interface, Dark Grey $CALL
Call
ModelDescriptionPrices From
Ergonomic Solutions Spacepole Essentials Plate for Epson TM-U220 Epson TM-U220 Printer Plate, straight angle. $82.50 View Product
Calibor Bond Paper 76MM X 76MM 50 Rolls/Box Plain Bond Paper 76MM X 76MM 50 Rolls/Box Plain $56.21 View Product
Calibor Ribbon Cartridge ERC30 34 38 Black indelible Black indelible ink ribbon for Epson TM-U220/TM-U230 $12.24 View Product
VPOS DB09F DB09F RS232 Printer Cable Powered USB Printer Cable 24V PUSB TO HOSIDEN & USB. $13.20 View Product
Epson TM-U220 Extended Warranty Epson Extended 3 Year warranty for use with the TM-U220 Series $108.79 View Product
Epson PS-180 AC Power Supply PS-180 AC adapter, Output: 24V, 2.1A $120.18 View Product
Epson UB-E04 Connect-It Ethernet Interface Epson 10 Base-T Ethernet Interface UB-E04-008 $170.78 View Product
Epson TMUBP0211 Parallel Interface Epson Parallel Interface (UB-P01II) $87.29 View Product
Epson UB-R04 802.11A B G N WLAN Interface Epson Wireless LAN Interface Card; IEEE802. $251.74 View Product
Epson UB-S09 9 Pin, Serial up to 115.2kb s with DM-D Port Epson UB-S09, Serial Interface Card $91.08 View Product
Epson UB-U03II, USB Interface Card Epson USB Interface without USB HUB or DMD Port (UB-U03II) $163.19 View Product
Epson UB-U04 Powered USB Interface Card Powered USB Interface Board (No Hub, No DM-D Port) $132.83 View Product
Epson WH-10, TM-Series Wall Hanging Bracket WH-10 (040) Wall hanging bracket - for TM-U220 TM-U230/TM-T88IV/TM-T88V/TM-T88VI/TM-T90 $77.17 View Product
POSMarket ERC30/34/38 CASSETTE RIBBON PURPLE Purple ERC30/34/38 Ribbon Cartridge to suit Epson Printers etc $6.55 View Product
POSMarket ERC30/34/38 RIBBON BLACK ERC 30/34/38 Black Ribbons to suit Epson TM-U220 Bixolon SRP-275 etc $4.54 View Product
Not all accessories and consumables are listed on our website. Please contact one of our experts using the 'Ask an Expert' form or call us on 1300 737 998 if you don't find what you're looking for.
FilenameSize
PDF Document Epson TM-U220 Brochure 112KB Download
