POSMarket SKU: Z1857
This model is available in 2 different configurations. Select a configuration from the list below or contact one of our experts on 1300 737 998 for help.
The Citizen CT-S280 low-cost thermal mini printer fits perfectly in a wide variety of logging applications. It combines high-speed, two-colour printing with a compact footprint and drop in paper loading for a reliable, versatile printer.
| Printing Method | Line thermal dot print method |
| Printing Width | 48mm / 384 dots |
| Dot Pitch | 8 x 8 dots / mm (203 dpi) |
| Printing Speed (Max.) | Max. 80mm/s. |
| Number of Columns | 32 columns - Font A: 12 x 24 dots horizontal and vertical 42 columns - Font B: 9 x 24 dots 48 columns - Font C: 8 x 16 dots |
| Character Size | Font A:1.50 x 3.00 mm Font B:1.13 x 3.00 mm Font C:1.00 x 2.00 mm |
| Character Table/Code Pages | Alphanumeric, International, PC437 PC850/852/857/858/860/863/864/865/866/ WPC1252/Katakana/Thai code 18 |
| Bar-code Type | UPC-A/E, JAN(EAN) 13/8 columns, ITF, CODE 39, CODE 128, CODABAR , CODE 93. |
| Line Spacing | 4.23mm (1/6 inch) (changeable using commands) |
| Paper feed method | Friction |
| Paper Type | Thermal Paper Roll |
| Paper Width | 58+0/-1 mm, |
| Paper Roll Diameter | Max 83.0mm. |
| Paper Thickness | 0.065 to 0.075mm |
| Paper Supply Method | Easy Paper Loading, Drop in and Print |
| Auto Cutter | NA |
| Indicators/Controls | Power LED. Feed Button,Error LED, Power switch |
| Emulation | Citizen |
| Print Buffer | 4K bytes / 45 bytes |
| NV Memory | 256 Kb (capable of storing user-defined characters and logos) |
| Sensors | Paper end Sensor |
| Drawer Port | NA |
| External Device Port | N/A |
| Interfaces | Serial (RS-232C compliant),Parallel. USB, |
| Driver available | WIN 7, CUPS |
| Software Utilities | Utility software to customize print speed, darkness and to set up user font, logo, maintenance counter, etc. |
| Power Supply | Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA Rated output: DC8.5V, 2.5 A |
| Power Consumption | Approx. 18 W (normal printing), 2W (standby) |
| External Dimensions (WxDxH) | 106W x 170D x 116.5H mm |
| Weight | 430g approx. AC adaptor 240g approx. |
| Operating Environment | 5 to 40 C, 10 to 85 % RH (no condensation) |
| Storage Environment | -20 to 60 C, 10 to 90 % RH (no condensation) |
| Reliability | Print head life: 50km, 100 million pulses |
| EMC/Safety Standards | UL, C-UL, FCC class A, TUV, GS, CE marking, C-tick |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| 280PAAB | CT-S280 Printer, Parallel Interface, Black | $308.00 | Add to Cart | |
| 280RSAB | CT-S280 Printer, Serial Interface, Black - Discontinued | $306.97 | Add to Cart |
| Model | Description | Prices From | |
|---|---|---|---|
| POSMarket Ink Ribbons | Ink printer ribbons and supplies. | $4.54 | View Product |
| POSMarket Paper Rolls | Large range of High Quality Thermal coated Paper rolls to suite most Point of Sale (POS) receipt printers, Cash Registers, EftPOS terminals, ATM's and kiosks. | $4.62 | View Product |
| POSMarket CAB-PAR1.8 Parallel | Parallel Cable 1.8m | $31.19 | View Product |
| Goodson CAB-PRUSB USB 2.0 | USB 2.0 A to B Cable | $6.34 | View Product |
| Zebra Software License Printer Enterprise | Software License Printer Enterprise | $1,313.07 | View Product |
| POSMarket Serial Printer Cable | RS232 serial Printer Cable | $19.80 | View Product |
| POSMarket USB PRINTER CABLE A-B BLACK 2M | USB cable A to B for Printers | $11.55 | View Product |
| Goodson USB Cable | USB Cable A to A; USB 2.0 A to B Cable | $6.90 | View Product |
| Filename | Size | ||
|---|---|---|---|
 |
CT-S280 Brochure | 101KB | Download |
|
CT-S280 Users Manual | 1MB | Download |
|
Citizen CTS Command Reference Manual | 3MB | Download |
