| Printing Method | Line thermal dot print method |
| Printing Width | 48mm / 384 dots |
| Dot Pitch | 8 x 8 dots / mm (203 dpi) |
| Printing Speed (Max.) | Max. 80mm/s. 60mm/s in label printing |
| Number of Columns | 32 columns - Font A: 12 x 24 dots horizontal and vertical
42 columns - Font B: 9 x 24 dots
48 columns - Font C: 8 x 16 dots |
| Character Size | Font A:1.50 x 3.00 mm
Font B:1.13 x 3.00 mm
Font C:1.00 x 2.00 mm |
| Character Table/Code Pages | Alphanumeric, International, PC437 PC850/852/857/858/860/863/864/865/866/
WPC1252/Katakana/Thai code 18 |
| Bar-code Type | UPC-A/E, JAN(EAN) 13/8 columns, ITF, CODE 39, CODE 128, CODABAR , CODE 93, PDF417, QR Code |
| Line Spacing | 4.23mm (1/6 inch) (changeable using commands) |
| Paper feed method | Friction |
| Paper Type | Thermal Paper Roll |
| Paper Width | 58+0/-1 mm, |
| Paper Roll Diameter | Max 83.0mm. Label paper 80.0mm |
| Paper Thickness | 0.06 to 0.1mm |
| Paper Supply Method | Easy Paper Loading, Drop in and Print |
| Auto Cutter | Guillotine,Full or Partial cut |
| Indicators/Controls | Power LED. Feed Button,Error LED, Paper Led, Power switch |
| Emulation | Citizen |
| Print Buffer | 4K bytes / 45 bytes |
| NV Memory | 256 Kb (capable of storing user-defined characters and logos) |
| Sensors | Paper end Sensor
Printer Cover open Sensor |
| Drawer Port | NA |
| External Device Port | N/A |
| Interfaces | Serial (RS-232C compliant), USB, |
| Driver available | WIN 7, CUPS |
| Software Utilities | Utility software to customize print speed, darkness and to set up user font, logo, maintenance counter, etc. |
| Power Supply | Rated input: AC 100 to 240 V, 50/60 Hz, 150 VA
Rated output: DC8.5V, 2.5 A |
| Power Consumption | Approx. 18 W (normal printing), 2W (standby) |
| External Dimensions (WxDxH) | 106W x 180D x 105H mm |
| Weight | 630g approx.AC adaptor 240g approx. |
| Operating Environment | 5 to 40 C, 10 to 85 % RH (no condensation) |
| Storage Environment | -20 to 60 C, 10 to 90 % RH (no condensation) |
| Reliability | Print head life: 50km, 100 million pulses
Auto cutter life: 1 million cuts (at normal temperature and humidity using recommended paper) |
| EMC/Safety Standards | UL, C-UL, FCC class B, TUV, CE marking, C-tick |
