| Scan Engine | CMOS Area Sensor. 752 x 480 pixels |
| Light Source | Aiming green LED |
| Scan Pattern | 752 x 640 Pixels |
| Scan Rate | Up to 60 frames/sec |
| Resolution | at PCS 0.9: 0.127 mm / 5 mil
Minimum PCS 0.9 |
| Depth of field | Code 39:
35 - 235 mm (res. 0.508 mm / 20 mil)
20 - 160 mm (res. 0.254 mm / 10 mil)
45 - 80 mm (res. 0.127 mm / 5 mil)
QR Code:
50 - 75 mm (res. 0.212 mm / 8.4 mil)
10 - 140 mm (res. 0.381 mm / 15 mil)
DataMatrix:
30 - 95 mm (res. 0.254 mm / 10 mil) |
| Tilt Angle | 360° |
| Pitch Angle | -65 to 0°, 0 to +65° |
| Skew Angle | -65 to 0°, 0 to +65° |
| Ambient Light Immunity | Fluorescent 10,000 lux max, Incandescent 10,000 lux max., Direct Sun 100,000 lux |
| Symbologies supported | 1D: JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 Databar (RSS), GS1 DataBar Limited, GS1 DataBar Expanded, Code 11, IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSM-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic,UK/Plessey
Postal Code: Chinese Post, Inteligent Mail Barcode,Korean Postal Authority code, POSTNET PLANET, Japan Postal, Netherland KIX Code, UK Postal, Australian Postal Code
2D Code: Aztec Code, Aztec Runes, Chinese Sensible Code, Codablock F, DataMatrix (ECC 200/ECC-000-140), Maxi Code, MicroPDF417, Micro QR Code, PDF417, QR Code |
| Programming Method | Scan barcodes from Manual |
| Indicators/Controls | 1 x Scan Key
Visual LED
Buzzer |
| Communication Type | Cabled |
| Interfaces | USB - Ver. 2.0, HID/COM, USB-A connector
RS232 - DB9 PTF connector with external power supply
Keyboard Wedge -with external Power Supply |
| Supply Voltage | 5 V 10 % (USB), 6 V (Keyboard Wedge and RS232) |
| Power Consumption | Max. 210 mA |
| Drop Specification | 1.5 m / 5 ft drop onto concrete surface
10 - 100 Hz with 2G for 1 hour |
| Environmental Sealing | IP42 |
| Operating Environment | 0 to 50 °C
RH 5 - 95 % (non-condensing) |
| Storage Environment | -20 to 60 °C
RH 5 - 95 % (non-condensing) |
| EMC/Safety Standards | CE, FCC, VCCI Class B, RoHS, IEC/EN 62471-1:2006, EN550022, EN55024 |
| External Dimensions (WxDxH) | 75.4 x 121.2 x 169.5 mm |
| Weight | 150 g (excl. cable) |
