RapidPOS HR-11+
POSMarket SKU: Z8602
The HR11+ is the perfect scanning for your 1D scanning requirements in any Retail, Office or Warehousing environment. The compact & lightweight design ensures comfort for all day operation, and with the advanced NLDC 1D Decoder chip, it's optimized for fast scanning of barcodes from paper or displayed on mobile screens
Product Overview
The HR11 Plus delivers outstanding scanning performance and excellent user experiences at an affordable price
Elegant Design
Blending ergonomics and aesthetics in its design, the HR11+ not only ensures operator comfort and productivity for intensive hand-held scanning but also meets the aesthetic needs of today's modern world
Durable Construction
The scanner has an IP42-sealed and drop resistant (1.5m) housing with no moving parts
Scanning from paper and screen
Equipped with Newland's NLDC technology (1D decoder chip), the HR11+ is optimized for fast scanning of 1D barcodes printed on paper or displayed on mobile phone & LCD screens. It is the perfect all-in-one solution for scanning product labels, and then scanning coupons or customer loyalty cards displayed on the customers mobile
Foldable smart stand
The HR11+ comes with a foldable smart stand, allowing you to quickly switch between hand-held scanning and hands-free scanning.
Applications
Retail chains, mobile payments, office automation, mail/parcel sorting and distribution
Product Specifications
| Performance | |
| Image Sensor | CCD 2500 |
| Illumination | Red LED (620nm~630nm) |
| Aiming | 40-480mm |
| Depth of Field EAN13 (13mil) | 80-180mm |
| Minimal Print Contrast | 20% |
| Scan Modes | Manual Mode Batch Mode Auto Mode Blink Mode Sense Mode Continuous Mode Command Trigger Mode |
| Scan Rate | 300 scans per second |
| Data Capture | |
| 1D | AIM 128 Code 11 Code32 Code 39 Code 93 Code 128 Codabar COOP 25 Deutsche 12 Deutsche 14 EAN-8 EAN-13 Febraban GS1-128 GS1 Databar (RSS) ISBN ISSN ITF-6 ITF-14 MSI-Plessey Plessey UPC-A UPC-E Industrial 2 of 5 Interleaved 2 of 5,Matrix 2 of 5 Standard 2 of 5 |
| Physical | |
| Dimensions (mm) | 101 x 68 x 145 (LxWxH) |
| Weight | 120g |
| Material | PC, ABS |
| Buttons | Trigger |
| Interfaces | USB |
| Notifications | Beep, LED indicator |
| Input Voltage | 5VDC +/- 5% |
| Current @ 5VDC Operating | 70.4 mA (typical) 96.8mA (max.) |
| Current @ 5VDC Standby | 57.6mA |
| Power Consumption | 352mW (typical) |
| Power Supply Input | DC5V, 1.5A |
| Power Supply Output | AC100-240V, 50-60Hz |
| Environmental | |
| Humidity | 5%~95% (non-condensing) |
| Electro Static Discharge (ESD) | +/-8 KV (direct discharge) +/-16 KV (air discharge) |
| Drop | 1.5m |
| Sealing | IP42 |
| Accessories | |
| Standard | USB Cable Stand |
| Certifications | |
| Certifications | FCC Part15 Class B CE EMC Class B RoHS IEC62471 KC |
| Model | Description | Price | Stock | |
|---|---|---|---|---|
| HR1150P-30F | HR11+ 1D Scanner Kit, Includes scanner, USB interface cable and hands free stand | $82.50 | Add to Cart |
Product Accessories
| Filename | Size | ||
|---|---|---|---|
 |
DS10051 NLS-HR11 Plus Datasheet | 327KB | Download |
|
HR-11 User Manual | 3MB | Download |
