PHYSICAL CHARACTERISTICS | |
Dimensions | Corded: 7.3 in. H x 3.0 in. W x 5.2 in. D 18.5 cm H x 7.6 cm W x 13.2 cm D Cordless: 7.3 in. H x 3.0 in. W x 5.6 in. D 18.5 cm H x 7.6 cm W x 14.2 cm D |
Weight | Corded: 10.9 oz./309 g; Cordless: 14.5 oz./411 g |
Colour | Industrial Green |
Supported Host Interfaces | USB, RS232, Keyboard Wedge |
Battery | PowerPrecision+ 3100 mAh Li-Ion rechargeable battery |
PERFORMANCE CHARACTERISTICS | |
Scans per full charge | 70,000+ |
Illumination | Two (2) warm white light LEDs |
Imager Field of View | Horizontal: 31°, Vertical: 23° |
Image Sensor | 1,280 x 960 pixels |
Skew/Pitch/Roll | Skew: ±60°; Pitch: ± 60°; Roll: ± 360° |
DECODE CAPABILITIES | |
1D | Code 39, Code 128, Code 93, Codabar/NW7, Code 11, MSI Plessey, UPC/EAN, I 2 of 5, Korean 3 of 5, GS1 DataBar, Base 32 (Italian Pharma) |
2D | PDF417, Micro PDF417, Composite Codes, TLC-39, Aztec, DataMatrix, MaxiCode, QR Code, Micro QR, Chinese Sensible (Han Xin), Postal Codes |
OCR | OCR-A/B, MICR-E13B, US Currency Serial Number |
USER ENVIRONMENT | |
Operating Temp. | Corded: -22° F to 122° F/-30° C to 50° C Cordless: -4° F to 122° F/-20° C to 50° C |
Drop Specification | Withstands multiple 8.0 ft. / 2.4 m drops to concrete |
Tumble Specification | 5000 tumbles @ 3.3 ft. (1 m) |
Sealing | Scanner: IP65 and IP67; FLB cradle: IP65 |
Ambient Light Immunity | 0 to 10,037 Foot Candles/0 to 108,000 Lux (direct sunlight) |
WIRELESS CONNECTIVITY | |
Bluetooth Radio | Bluetooth Class 1, Version 4.0 (LE), serial port (SPP) and HID profiles |
Radio Range | Direct line of sight in open air : Class 1: Minimum 300 ft. (100.0 m); Class 2: Minimum 30 ft. (10.0 m) |
Model | Description | Price | Stock | |
---|---|---|---|---|
DS3608-HP3U4602VZW | DS3608 USB Kit. Includes DS2608-HP Scanner & High current shielded USB cable | $909.54 | Add to Cart |
Model | Description | Prices From | |
---|---|---|---|
Zebra EA3600-T1CP-00 | 3600 Series Ethernet Adapter | $944.69 | View Product |
Zebra DC Line Cord with Filter for 3600 Series | DC Line Cord with Filter Used with 3600 Series (Except SAC3600-4001CR) Level 6 AC/DC Power Supply Part PWR-BGA12V50W0WW. | $25.30 | View Product |
Zebra OneCare Essential DS3608 | With three service levels to choose from - Essential, Select and Premier - you'll find a Zebra OneCare for Printers offering that will meet your service requirements and your budget. | $60.72 | View Product |
Zebra Onecare Select DS3608 | Onecare Select DS3608, Next Business day, 3 Year comprehensive | $75.90 | View Product |
Zebra Stand intellistand adj ds3608 blk | Stand intellistand adj ds3608 blk | $94.88 | View Product |
Zebra Multidock Battery 4-Bay li3678/ds3678 | Multidock Battery 4-Bay li3678/ds3678 | $371.91 | View Product |
Zebra PSU Kit 12V 4.16A 50W | Power Supply Kit | $75.90 | View Product |
Zebra Cable Data usb bc1.2 Coiled 2.8m -30c | Cable Data usb bc1.2 Coiled 2.8m -30c | $113.85 | View Product |
Zebra Cable Data Usb -30c bc1.2 Coiled 2.7m | Cable Data Usb -30c bc1.2 Coiled 2.7m | $101.20 | View Product |
Zebra Cable-Y Power Stealer DS3600-VC5090 9ft -30C | Cable-Y Power Stealer DS3600-VC5090 9ft -30C | $126.50 | View Product |
Zebra Cable Data USB-C Shielded 2m Str BC1.2 | Cable Data USB-C Shielded 2m Str BC1.2 | $87.29 | View Product |
Zebra Cable Data Scanner rs232 2.8m -30C Pwr Pin 9 | Cable Data Scanner rs232 2.8m -30C Pwr Pin 9 | $113.85 | View Product |
Zebra Cable Data Scanner rs232 db9f 6m cld txd2 | Cable Data Scanner rs232 db9f 6m cld txd2 | $92.35 | View Product |
Zebra Cable Data Scanner Usb-Shielded 2M str bc1.2 | Cable Data Scanner Usb-Shielded 2M str bc1.2 | $44.28 | View Product |
Zebra Cable Data Scanner rs232 2.8m low tem cld | Cable Data Scanner rs232 2.8m low tem cld | $101.20 | View Product |
Zebra Bracket Cradle Vibration Dampen stb36/flb36 | Bracket Cradle Vibration Dampen stb36/flb36 | $94.88 | View Product |
Zebra Cable Data Scanner USB 4.6M CLD | Cable Data Scanner USB 4.6M CLD | $113.85 | View Product |
Zebra Tool Balancer Pulley | Tool Balancer Pulley | $180.90 | View Product |
Filename | Size | ||
---|---|---|---|
ds3608 Quick Start Guide | 9MB | Download | |
ds36xx Brochure | 962KB | Download | |
ds3678 Quick Start Guide | 3MB | Download | |
flb3678 Quick Reference Guide | 2MB | Download |
